High Efficiency Compaction

GYS08J Single Drum Road Roller

Name: GYS08J Single Drum Road Roller
Brand: SINOMACH
SKU: GYS08J

The SINOMACH GYS08J Single Drum Road Roller is designed for efficient and reliable compaction across large-scale construction sites including roads, dams, railways, and…

Engine Power

43kW

Centrifugal Force

85KN kN

Operating Weight

8 t

Global Shipping

2-Year Warranty

Parts Available

24/7 Support

Product Overview

The SINOMACH GYS08J Single Drum Road Roller is designed for efficient and reliable compaction across large-scale construction sites including roads, dams, railways, and airports. With a rated output of 42kW and an operating weight of 8000kg, this roller is equipped to handle semi-stick and non-stick materials such as sand, gravel, and rock fill effectively. Its compact design and exceptional gradeability make it versatile in demanding construction environments.

Xinchai 4-cylinder supercharged engine

Large power output ensures high efficiency during operations

Compliant with China Stage II emission standard

Environmentally friendly for sustainable use

Mechanical drive system

Offers 5 forward speeds and 1 reverse speed for versatile operation

Hydraulic vibration with electric control

Reliable compaction performance with adjustable amplitude

Why Choose the GYS08J?

Xinchai 4-cylinder supercharged engine

Compliant with China Stage II emission standard

Mechanical drive system

Hydraulic vibration with electric control

Articulated hydraulic steering

Special gearbox

Quick Specs

Engine Power43kW

Centrifugal Force85KN kN

Operating Weight8 t

Export & Trade Information

Trade Terms

EXW / FOB / CIF (quoted per destination)

Port of Loading

Shanghai / Qingdao, China

Lead Time

30–45 days, subject to configuration

MOQ

1 unit

Need Help?

Our experts are ready to help you choose the right equipment for your needs.

ISO 9001:2015 · CE

Quality Certified

Call us: +86 189-8195-8565 Email us: [email protected]

Technical Specifications

Complete product specifications and parameters

Basic Parameters

Drive TypeMechanical Drive

Weight ClassSmall

Operating Weight8000 kg

Engine Power42 kW

Centrifugal Force85KN

Static Linear Load245 N/cm

Max Operating Speed15.5 km/h

Rolling Width1650 mm

Compaction Width1650 mm

Engine

Engine ModelA498BG

Engine BrandXinchai

Engine TypeSupercharged Diesel

Number of Cylinders4

Displacement4.3 L

Engine Power42 kW

Rated Speed2200 rpm

Emission StandardChina Stage II

Vibration System

Vibration Frequency48 Hz

Nominal Amplitude0.5mm

Centrifugal Force (High)85 kN

Centrifugal Force (Low)0 kN

Vibration Control TypeHydraulic, Electric

Drum Specifications

Drum Diameter1200 mm

Drum Width1650 mm

Drum Shell Thickness20 mm

Front Drum Diameter1200 mm

Rear Drum Diameter0 mm

Wheel Specifications

Number of Wheels (Front)2

Number of Wheels (Rear)0

Tyre Size12.00-20-16PR

Wheel TypePneumatic

Wheel Diameter1200 mm

Transmission System

Transmission TypeMechanical

Drive Type2WD

Travel Speed (Forward)2.2/4.2/7.5/12.5/15.5 km/h

Travel Speed (Reverse)2.5 km/h

Speed ControlManual

Number of Gears6

Steering System

Steering TypeHydraulic Articulated

Steering Angle45 °

Min Turning Radius (Inside)6000 mm

Min Turning Radius (Outside)12000 mm

Brake System

Service BrakeHydraulic Caliper Disc Brake

Parking BrakeMechanical Drum Brake

Hydraulic System

Hydraulic Pump TypeHigh Efficiency

System Pressure18 MPa

Hydraulic Oil Flow120 L/min

Water System

Water Tank Capacity200 L

Water Spray TypeElectric Controlled Spray

Spray ControlAdjustable

Dimensions

Overall Length5130 mm

Overall Width1830 mm

Overall Height2570 mm

Wheelbase2650 mm

Ground Clearance300 mm

Gradeability

Gradeability25 %

Max Working Slope14 °

Fluid Capacities

Fuel Capacity150 L

Hydraulic Tank Capacity75 L

Engine Oil Capacity10 L

Cooling System Capacity20 L

Cabin

Cabin TypeOpen Cabin

14 categories

* Specifications may vary based on configuration. Please confirm with our sales team.

Total62 specs

GYS08J Single Drum Road Roller

Product Overview

Xinchai 4-cylinder supercharged engine

Compliant with China Stage II emission standard

Mechanical drive system

Hydraulic vibration with electric control

Why Choose the GYS08J?

Quick Specs

Export & Trade Information

Need Help?

Technical Specifications

Basic Parameters

Engine

Vibration System

Drum Specifications

Wheel Specifications

Transmission System

Steering System

Brake System

Hydraulic System

Water System

Dimensions

Gradeability

Fluid Capacities

Cabin

Key Features

Xinchai 4-cylinder supercharged engine

Compliant with China Stage II emission standard

Mechanical drive system

Hydraulic vibration with electric control

Articulated hydraulic steering

Special gearbox

Gas-assisted hydraulic caliper disc brake

Rear hood with large angle opening

Durable hydraulic components

Applications
